HGLRC DS230 Drone Soccer FPV Analog version Zeus Nano 350mW VTX Caddx Ant Eco
Features:
*Long battery life performance to meet various scenarios;
*Spherical explosion-proof material frame, you can do whatever you want;
*Support multi-color LED light strip adjustment, you can quickly identify
yourself and the enemy in multiplayer mode;
*The protective cover is available in three colors, including orange, yellow and grey,
which are easy to distinguish.
Product Name: HGLRC DS230 3S FPV Analog version
Weight:175.2g
HGLRC DS230 Frame
Type:3-inch frame
Wheelbase:126mm
Size:230*230*220mm
Zeus F722 mini flight controller
Gyro:BMI270
Input voltage:3-6S Lipo
BEC output:9V1.5A/5V/2A
Firmware:HGLRCF722
Zeus 28A BL_S ESC
Input voltage:3-6S
Continuous current:28A
Peak current:35A (10 seconds)
Firmware:BLS-F-H-40
Zeus Nano 350mW VTX
Output Power:PIT/25/100/200/350mW
Input Voltage:DC 5V
Antenna:IPEX
Caddx Ant Eco Camera
Input Voltage:DC 3.3-6V
Dimension:14mm*14mm*16mm
AEOLUS 1404 4800KV Motor
Motor KV:4800KV
Input Voltage:3-4S
Mounting hole:4*M2-∅9
Gemfan3016 -PC 3 inch 3 blade propeller
Quantity:4 CW & 4 CCW
Package Includes:
1x Zeus F722 mini flight controller（270）
1x Zeus 28A BL_S ESC
1x Zeus Nano 350mW VTX
1X Caddx Ant Eco Camera
1X DS230 Frame(Orange / yellow / gray)
4X AEOLUS 1404 4800KV Motor
8x Gemfan3016 -PC 3 inch 3 blade propeller（pcs）
1x Receiver (optional)
Recommended Battery:
3S:850mah
See Manual here
